How should a novice operate a water sprinkler truck correctly?
1. Check the lubricating oil level in the sprinkler‘s gearbox to the lower edge of the screw plug hole. If not, add gear oil.
2. Check the sprinkler lever of the sprinkler to make it in the neutral position. Check the position of the handle of the power take-up box so that it is horizontal to the right position, make it horizontal to the right position, check the throttle controller to make it the minimum. .
Secondly, the operation of the pump and power take-off
1. Start connecting the relevant pipeline and start the engine. When the original pressure gauge reading reaches 0.3Mpa, step on the clutch pedal, open the power lever control switch, and slowly loosen the clutch (too fast to damage the power take-off and gearbox). Keep it up. The operating speed of the pump can be controlled by the throttle controller.
2. Stop pushing the throttle controller to the minimum. Press the clutch pedal to pull the power take-off control switch back to the original position to disengage the power take-off box.
Thirdly, the inspection after usage:
1. Check if the power take-off control switch is back and check if the throttle controller is at the minimum position.
2. Check the position of the valve handle, both closed.
Fourth, sprinkler water intake precautions:
1. When the sprinkler uses the pond and the ditch is the working water source, it should be noted that all the ends of the suction pipe are not in the water. In addition, it is strictly forbidden to remove the filter device when water is absorbed, so as to avoid inhaling excessive stones, silage or drifting debris. If the water source is shallow, you need to dig deeper into the water to ensure that it does not contain debris and does not enter the air.
2. When the inlet pipe must be vacuumed, the inlet pipe system must maintain a certain degree of vacuum to draw water into the tank. The inlet pipe system must be sealed reliably, the hose can not be damaged, and the hard pipe can not have cracks, otherwise it will cause air leakage, otherwise it will cause the water to be sucked.
3. The parking gear sprinkler must be stopped during the parking before the water is absorbed or before the water is sprinkled.
